Plot and House Scheme Drawing Plan Details :

To do this accurately, I'll outline a sample plan first, and then you can modify it as needed — or provide your custom requirements for a more tailored plan.

🏡 SAMPLE PLOT AND HOUSE DRAWING PLAN

📌 Plot Details

• Plot Size: 30 ft × 40 ft (1200 sq. ft)
•

• Orientation: East-facing
•

• Setbacks: 3 ft on all sides
•

• Built-up Area: ~900–1000 sq. ft (Ground floor)

🏠 Ground Floor Plan – 2BHK Layout

RoomSizeLiving Room14 ft × 12 ftDining Area10 ft × 8 ftKitchen10 ft × 8 ft (with utility)Master Bedroom12 ft × 12 ft (with attached bath)Bedroom 210 ft × 12 ftCommon Bathroom6 ft × 8 ftPooja Room5 ft × 4 ftStaircaseOutside/Inside (optional)Parking10 ft × 12 ft (1 car)Small GardenFront yard (4 ft × 10 ft)

🏗️ Construction Details

• Foundation: RCC framed structure
•

• Walls: Brick/Concrete block with plastering
•

• Roofing: RCC slab
•

• Flooring: Vitrified tiles
•

• Windows: UPVC or Aluminum sliding windows.
