Toto Spares, Toto Parts, Toto Spare Parts, Spare Code No : DH825G.
The TOTO DH825G is a battery connection cable (wiring harness) used in TOTO automatic concealed urinal flushing systems. Its purpose is to provide a secure electrical connection between the battery box and the electronic controller.
Uses of the TOTO DH825G
- Transfers battery power from the DH824G battery box to the DH817G sensor/controller, allowing the automatic flush system to operate.
- Provides a reliable electrical connection between the system's power supply and control electronics.
- Supports automatic flushing by ensuring the controller has the power needed to detect users and activate the solenoid valve.
- Facilitates maintenance and replacement, as the wiring harness can be replaced if it becomes damaged or worn without replacing the entire flush system.
- Maintains stable electrical performance, helping reduce issues caused by loose or damaged wiring.
Role in the system
In a typical TOTO automatic urinal flush system:
- DH824G stores the batteries and supplies electrical power.
- DH825G carries that power to the DH817G sensor/controller.
- DH817G detects the user and sends a control signal.
- DH818G solenoid valve opens to allow the programmed flush, then closes automatically.
The DH825G is therefore an essential electrical interconnection component. Although it does not detect users or control water flow directly, it enables the electronic components to receive power and function correctly.
The TOTO DH825G is a power connection cable (battery harness/wiring assembly) used in certain TOTO automatic concealed urinal flush systems. It connects the battery box (DH824G) to the sensor/controller (DH817G), providing the electrical power needed for the system to operate.
TOTO DH825G details
- Part Number: DH825G
- Part Type: Battery connection cable / wiring harness
- Function: Transfers electrical power from the battery box to the electronic controller.
- Application: TOTO concealed automatic urinal flush systems that use the DH817G controller and DH824G battery box.
Main functions
- Connects the DH824G battery box to the DH817G sensor/controller.
- Provides a reliable electrical connection for battery-operated flush systems.
- Ensures the controller receives power to detect users and operate the flush cycle.
- Designed as a genuine replacement spare for maintenance or repair of compatible TOTO automatic urinal systems.
Related components in the system
- DH817G – Sensor and controller
- DH818G – Solenoid valve
- DH824G – Battery box
- DH825G – Battery connection cable (wiring harness)
- DH867G – Sensor cover plate
- DH868G – Stop valve
If you're looking for the uses, wiring diagram, or compatible models for the DH825G, I can provide those as well.
