TOTO TC385-E1 — As-Built Drawing Details
For an as-built drawing / installation drawing, the verified information for TC385-E1 is:
ItemDetailsTOTO Spare No.TC385-E1DescriptionRound Rubber CushionQuantity4 Nos. / setComponentToilet seat/cover cushionInstallationFitted underneath the toilet seat/coverFunctionSupports/cushions the seat against the ceramic WCAssociated seat seriesTC385MaterialRubber cushionDrawing statusSpare-part/component detail
The spare-parts listings independently identify TC385-E1 as “Round Rubber Cushion (X4 nos)”. B
Be Chennai
+1
As-built drawing notation
You can show it on the drawing approximately as:
TOTO TC385 SEAT & COVER
┌─────────────────────────────┐
│ │
│ SEAT / COVER │
└─────────────────────────────┘
● ●
TC385-E1 TC385-E1
Rubber Rubber
Cushion Cushion
● ●
TC385-E1 TC385-E1
Rubber Rubber
───────────────────────────────
CERAMIC WC PAN
Drawing callout:
TC385-E1 – ROUND RUBBER CUSHION, 4 NOS. PER SET, INSTALLED BELOW TOTO TC385 SEAT & COVER.
For reference, TOTO's current specification information identifies TC385CV as an elongated seat & cover, with dimensions 368 W × 467 D × 55 H mm, and TC385VS as another TC385 seat variant at 369 W × 455 D × 62 H mm. A
Asiatoto Spares
+1
Important: I could verify the part description and quantity, but I could not verify an official TOTO dimensioned drawing for the individual TC385-E1 cushion. Therefore, I would not put an assumed cushion diameter/thickness on an as-built drawing without the manufacturer's part drawing.
If you need it, I can prepare a professional AutoCAD-style as-built drawing specification for TC385-E1, including plan, elevation, section, 4 cushion locations, dimensions and drawing notes.
