🏠 Basic Housing Plan Scheme (ASCII Drawing)

Single-floor, 2-Bedroom Layout

 _____________________________________________
|                     |                       |
|      BEDROOM 1      |      BEDROOM 2        |
|     (12' x 12')     |     (12' x 12')       |
|_____________________|_______________________|
|                                           |
|                 LIVING ROOM               |
|                 (15' x 18')               |
|___________________________________________|
|        |                     |             |
| KITCHEN|      DINING AREA    |  BATHROOM   |
| (8x10) |       (10x10)       |   (6x8)     |
|________|_____________________|_____________|
|                                         |
|                 VERANDA                 |
|_________________________________________|

Alternate – Compact Housing Plan (1 Bedroom)

 _______________________________
|             |                 |
|  BEDROOM    |   LIVING ROOM   |
|   (10x12)   |    (12x14)      |
|_____________|_________________|
|             KITCHEN           |
|              (8x10)           |
|_______________________________|
|   BATH (6x8)  |   ENTRY       |
|_______________|_______________|
