Toto spares, Toto parts, Toto spare parts, Spare code no : S1015-RO-B

TOTO Spare Part: TOTO S1015-RO-B Ceramic Cartridge

S1015-RO-B is a ceramic faucet cartridge (spindle valve) used inside many TOTO basin taps / sink faucets. It controls the opening and closing of water flow when the tap handle is turned.

Basic Specifications

• Part number: S1015-RO-B
•

• Brand: TOTO
•

• Type: Ceramic cartridge / faucet spindle
•

• Function: Water control valve inside faucet
•

• Rotation: 90° turn operation
•

• Color code: Blue (cold water side)

Function

This cartridge works as the main internal valve of the faucet:

• Opens or closes water flow
•

• Controls water pressure and sealing
•

• Prevents dripping or leakage when the handle is closed
•

• Provides smooth handle rotation

Inside the cartridge are ceramic discs that seal tightly to stop water flow.

Difference Between Similar Parts

Part NumberColorUseS1015-RO-ARedHot water sideS1015-RO-BBlueCold water side

Both are usually installed as a pair in dual-handle faucets.

Common Problems (When Replacement Is Needed)

Replace the cartridge if you see:

• Faucet dripping even when closed
•

• Loose or stiff handle movement
•

• Water leakage around handle

TOTO : Control unit, toto Powercable, toto Rubber flapper, toto…

Toto spares, Toto parts, Toto spare parts, Spare code no : S1015-RO-A,

TOTO spare part – S1015-RO-A is a faucet spindle / ceramic cartridge used inside a TOTO tap (faucet). It is the internal valve that controls water flow when you turn the handle.

Basic Details

• Part number: S1015-RO-A
•

• Brand: TOTO
•

• Type: Faucet spindle / ceramic cartridge
•

• Use: Internal valve for washbasin or sink faucet
•

• Rotation: About 90° turn operation
•

• Color identification: Usually red (hot-side cartridge)

Function

This part is the “heart of the tap” (often called jantung keran). It:

• Opens and closes the water flow
•

• Controls water pressure and sealing
•

• Prevents leakage when the tap is closed

If this part fails, the faucet may drip continuously or become hard to turn.

Common Signs It Needs Replacement

• Water leaking from the spout even when closed
•

• Handle turns too freely or gets stuck
•

• Uneven water control

Approximate Spare Price

Typical market price internationally is around ₹500–₹900 (or about ₹80k–₹90k Indonesian Rupiah depending on seller).

TOTO : Control unit, toto Powercable, toto Rubber flapper, toto Signal Cable& Conduit Pipe, toto Right hook,

toto Screw, toto Concealed Automatic Urinal Flush Valve, toto Shower Hanger &…

Toto spares, Toto Parts, Toto spare parts, S[pare code no : P853-STIV2

TOTO spare part – P853-STIV2 is a soft-close mechanism (hinge/damper unit) for the toilet seat lid used in some TOTO toilet seats and eco-washer seat covers.

Basic Details

• Part code: P853-STIV2
•

• Alternative code: I387-STIV3
•

• Type: Soft-close hinge / soft landing mechanism
•

• Application: Toilet seat lid soft-closing system
•

• Brand: TOTO
•

• Used in: TOTO seat covers / eco-washer seats where soft-close lid is provided.

Function

• Controls the slow and silent closing of the toilet lid
•

• Prevents slamming of the seat cover
•

• Improves durability of the seat and hinges
•

• Provides smooth damping action when the lid is lowered.

Typical symptoms when it fails

• Lid falls down quickly instead of closing slowly
•

• Uneven closing (one side faster than the other)
•

• Noise or looseness in the hinge.

Replacement notes

• Usually replaced as a pair (left + right soft-close units).
•

• Must match the seat model number to ensure compatibility.

TOTO : Control unit, toto Powercable, toto Rubber flapper, toto Signal Cable& Conduit Pipe, toto Right hook,

toto Screw, toto Concealed Automatic Urinal Flush Valve, toto Shower Hanger & Screw, toto check nut & lock on cartridge…

Terrace floor plan : Here’s a comprehensive overview of terrace roof plan details that architects, civil engineers, and builders usually include in construction drawings:

1. Roof Layout

• Plan view showing the shape and extent of the terrace roof.
•

• Indicate slopes/pitch for water drainage (usually 1–2% slope for flat terraces).
•

• Show boundaries with parapet walls, edges, and projections.

2. Structural Details

• Beam and slab layout: Location and size of beams supporting the roof slab.
•

• Column positions: Alignment of load-bearing columns from lower floors.
•

• Roof slab thickness: Typically 4–6 inches for residential terraces.
•

• Reinforcement details: Type and spacing of steel bars (main & distribution).

3. Drainage System

• Rainwater pipes: Position of downpipes or scuppers.
•

• Gutters and channels: For proper water collection and flow.
•

• Slope direction: Arrow marks showing the slope towards drains.

4. Waterproofing Layers

• Membrane type: Bituminous felt, PVC, or liquid-applied membranes.
•

• Slope direction: Ensure no ponding water accumulates.
•

• Protection layer: Tiles or pavers over waterproofing (if designed as a usable terrace).

5. Terrace Utilities

• HVAC units: Space for air conditioners, exhaust fans, or solar…

Second Floor Details : A Second Floor Plan is a top-view layout of the second floor of a building, showing the arrangement of rooms, structural elements, and functional spaces. It’s similar to a first floor plan but usually accommodates additional bedrooms, terraces, or utility areas. 🏢📐

📋 Main Details in a Second Floor Plan

1️⃣ Room Layout

The second floor often has:

• Bedrooms (Guest or Family bedrooms)
•

• Bathrooms / Toilets
•

• Terrace / Balcony / Sit-out area
•

• Study / Home Office / Library
•

• Family Lounge / Lounge area
•

• Utility / Storage rooms

Example schematic:

 ------------------------------------------------- | TERRACE / BALCONY | |-------------------------------------------------| | MASTER BEDROOM | |-----------|-------------------|-----------------| | BEDROOM | FAMILY LOUNGE| BEDROOM | |-----------|-------------------|-----------------| | TOILET | STAIRCASE LANDING | UTILITY | -------------------------------------------------

2️⃣ Wall Thickness

• External walls: 230 mm (9 inch)
•

• Internal walls: 115 mm (4.5 inch)

3️⃣ Doors and Windows

• Doors labeled D1, D2, etc., with sizes
•

• Windows labeled W1, W2, etc., with sizes
•

• Ventilators for light and air circulation

4️⃣ Dimensions

• Room sizes (length × width)
•

• Staircas…

First floor plan details : A First Floor Plan is a technical layout drawing of the first floor of a building, showing rooms, walls, doors, windows, and other structural details, similar to a ground floor plan but for the floor above ground. 🏠📐

📋 Main Details in a First Floor Plan

1️⃣ Room Layout

Shows all functional spaces on the first floor.

Common rooms:

• Bedrooms (Master / Kids / Guest)
•

• Bathrooms / Toilets
•

• Balcony / Terrace
•

• Drawing / Family Lounge / Study Room
•

• Staircase landing
•

• Utility / Storage areas

Example layout (schematic):

 ------------------------------------------------- | BALCONY / TERRACE | |-------------------------------------------------| | MASTER BEDROOM | |-----------|-------------------|-----------------| | BEDROOM | FAMILY LOUNGE | BEDROOM | |-----------|-------------------|-----------------| | TOILET | STAIRCASE LANDING | UTILITY | -------------------------------------------------

2️⃣ Wall Thickness

Shows internal and external wall sizes, usually same as ground floor unless modified.

• External walls: 230 mm (9 inch)
•

• Internal walls: 115 mm (4.5 inch)

3️⃣ Doors and Windows

• Doors: D1, D2… with size in mm
•

• Windows: W1, W2… with size in mm
•

• Ventilators for air circulation

4️⃣ Dimensions

• …

Ground Floor Plan Details :

A Ground Floor Plan is a technical drawing that shows the layout of the ground level of a building, including rooms, walls, doors, windows, and dimensions. It helps builders understand how the ground floor should be constructed. 🏠📐

📋 Main Details in a Ground Floor Plan

1️⃣ Room Layout

Shows all rooms and spaces on the ground floor.

Example rooms:

• Living Room
•

• Bedrooms
•

• Kitchen
•

• Dining Area
•

• Toilet / Bathroom
•

• Staircase
•

• Car Parking / Portico

Example layout:

 ------------------------------------------------- | PORTICO / CAR PARK | |-------------------------------------------------| | LIVING ROOM | | | |-----------|-------------------|-----------------| | BEDROOM | DINING | BEDROOM | |-----------|-------------------|-----------------| | KITCHEN | TOILET / BATH | STAIRCASE | |-----------|-------------------|-----------------|

2️⃣ Wall Thickness

Shows external and internal wall sizes.

Common sizes:

• External wall: 230 mm (9 inch)
•

• Internal wall: 115 mm (4.5 inch)

3️⃣ Doors and Windows

Doors and windows are marked with symbols and sizes.

Example:

• D = Door (900 × 2100 mm)
•

• W = Window (1200 × 1200 mm)
•

• V = Ventilator

4️⃣ Dimensions

Shows the length and width of rooms and distance between…

Base column centre line drawing : A Base Column Centre Line Drawing is a structural layout drawing that shows the exact center positions of all columns in a building foundation. It is mainly used for marking columns on site before footing excavation. 🏗️📐

📐 What is a Base Column Centre Line Drawing?

It is a plan that shows:

• Grid lines (horizontal & vertical reference lines)
•

• Center point of each column
•

• Distance between columns
•

• Column numbering

Engineers and surveyors use it to mark column locations accurately on the ground.

📋 Main Details in the Drawing

A typical base column centerline drawing includes:

1️⃣ Grid Lines

• Horizontal lines: 1, 2, 3, 4…
•

• Vertical lines: A, B, C, D…

Example grid:

 A B C D -------------------------------- 1 | C1 | C2 | C3 | | -------------------------------- 2 | C4 | C5 | C6 | | -------------------------------- 3 | C7 | C8 | C9 | | --------------------------------

2️⃣ Column Marking

Each column is marked with:

• Column number (C1, C2, C3…)
•

• Column size (example: 230×450 mm)

Example:

C1 = 230 × 450 mm C2 = 300 × 450 mm

3️⃣ Centre-to-Centre Dimensions

Distance between columns is clearly given.

Example:

A to B = 3.5 m B to C = 3.5 m 1 to 2 = 4.0 m 2 to 3 = 4.0 m

4️⃣ Reference…

Ground floor Scheme Drawing : If you need a Ground Floor Scheme Drawing Plan, it usually means a simple layout plan showing room arrangement, dimensions, and basic utilities for the ground floor of a building. 🏠📐

Below is a basic example of a ground floor scheme plan for a small house:

 ------------------------------------------------- | PORTICO / CAR PARK | |-------------------------------------------------| | LIVING ROOM | | | |-----------|-------------------|-----------------| | BEDROOM | DINING | BEDROOM | | | | | |-----------|---------|---------|-----------------| | KITCHEN | TOILET | BATH | STAIRCASE | |-----------|---------|---------|-----------------| | BACK OPEN SPACE | -------------------------------------------------

📋 What a Ground Floor Scheme Plan Normally Shows

• Plot boundary and building outline
•

• Room layout (Living, Bedroom, Kitchen, etc.)
•

• Doors and windows
•

• Staircase position
•

• Toilet / bathroom
•

• Car parking / portico
•

• Basic dimensions

📐 Common Size Example (Small House)

Example for 30 × 40 ft plot:

• Living room – 12 × 15 ft
•

• Bedroom – 10 × 12 ft
•

• Kitchen – 8 × 10 ft
•

• Toilet – 4 × 7 ft
•

• Dining – 10 × 10 ft

🛠 Drawings Usually Included

A complete building drawing set includes:

1. Ground floor…

Toto spares, Toto parts, Toto spare parts, Spare code no : SHXBE15,

TOTO spare part: SHXBE15 is a solenoid valve used in TOTO automatic sensor faucet (touchless tap) systems. It is also referenced by an alternate code 9E4008.

🔧 SHXBE15 – Spare Part Details

• Part number: SHXBE15
•

• Alternate code: 9E4008
•

• Part name: Solenoid Valve
•

• Brand: TOTO
•

• Application: Automatic sensor faucets / touchless basin taps
•

• Installation location: Inside the control box or water supply line under the wash basin.

⚙️ Function

The solenoid valve (SHXBE15) controls the water flow electronically in a sensor faucet.

How it works:

1. The infrared sensor detects hands under the faucet.
2.

3. The signal goes to the controller unit.
4.

5. The SHXBE15 solenoid valve opens, allowing water to flow.
6.

7. When hands are removed, the valve closes automatically, stopping water.

This system helps with:

• Touchless operation (hygiene)
•

• Water saving
•

• Automatic shut-off safety.

🧩 Related Parts in the Same System

Common components used with SHXBE15:

• Sensor unit (infrared hand detection)
•

• Controller unit / control board
•

• Flow regulator
•

• Power supply (battery or AC adapter)
•

• Faucet body.

✅ Simple explanation:

SHXBE15 = the electric water valve that opens and closes water in a TOTO…
